Numero di articolo: 7400100028
Fusibile della batteria NH1 6 poli
Marca HIS, interruttore sezionatore, max. 250 A
Disponibilità
3 Pezzo disponibile
Merkmale
Descrizione
purpose: connection battery inverter
on battery
bottom: up to 2x +/- battery
with M8 up to 70mm²
top: 3x +/- with M10 up to 70mm²
and 1x +/- 48VDC 10A voltage tap
with 1x +/- screw clamp
6x M32 & 1xM20 blind plugs included
H540xW540xD230mm; IP 65
weight: ca. 20 kg
without NH1 fuse links
on battery
bottom: up to 2x +/- battery
with M8 up to 70mm²
top: 3x +/- with M10 up to 70mm²
and 1x +/- 48VDC 10A voltage tap
with 1x +/- screw clamp
6x M32 & 1xM20 blind plugs included
H540xW540xD230mm; IP 65
weight: ca. 20 kg
without NH1 fuse links
