Numero di articolo: 4400200172
Sensore di radiazione Si-RS485-TC-T-MB
Marca Meteocontrol 423.016
Disponibilità
Disponibile
Merkmale
Profondità [mm]
40
Larghezza [mm]
155
Altezza [mm]
85
Peso [kg]
0,285
N. di registrazione RAEE DE
20681702
Descrizione
The SI-RS485TC-T is used to
record the solar irradiance intensity.
Furthermore, it can also record
the module temperature of the measurement cell.
Supply voltage:
24 V DC (12...28 V DC)
Current consumption:
typical 35 mA
Galvanic isolation:
24 V DC (12...28 V DC)
Current consumption:
typical 35 mA
Galvanic isolation:
1000 V between supply and RS485 bus
Current measuring shunt:
0.1 (TK = 30 ppm/K)
Measuring range:
01400 W/m²
0.1 (TK = 30 ppm/K)
Measuring range:
01400 W/m²
cable length: 3m
